32-channel PWM DMX LED dimming driver


Ø LNX-280DVL is a constant voltage, multi-drive port, port can be aggregated, and supports RDM centralized control management DMX decoder driver developed by Ling En Technology.

Ø LNX-280DVL has 8 PWM drive ports for constant voltage lamps, and each port has 5 terminals: V+/R/G/B/W, among which the W white light can be configured in different working modes through RDM.

Ø LNX-280DVL provides a wide voltage working range of 5-48V, and the maximum current of each dimming channel is 4A,  that is, the total current of the dimming port of each RGBW lamp is 16A, and the maximum current of the complete dimming is 128A. The decoder can be connected to a 12V / 24V / 48V constant voltage light bar or lamp, and the decoder has a power supply anti-reverse function and anti-overshoot function.

Ø LNX-280DVL can remotely configure the aggregation mode of each port through RDM: 2-port aggregation, 4-port aggregation or 8-port aggregation can be configured. By driving the port aggregation, it can realize the dimming of  higher power lamps in a DMX channel. , Or realize the installation of some special application scenarios.


Click to View Detailed Info

Write a review

Note: HTML is not translated!
    Bad           Good

32 Channels PWM DMX LED dimmer

  • Brand: LINETX
  • Product Code: LNX-280DVL
  • Availability: In Stock
  • $385.00

  • Ex Tax: $385.00
